Preparatory measurements in Hamburg

One contribution to FESSTVaL comes from the Meteorological Institute of the University of Hamburg and the Max Planck Institute for Meteorology. For 2020, the main campaign for the main FESSTVaL in Lindenberg was relocated to Hamburg, so that additional and preparatory measurements will be carried out in the city this summer.
The aim is to investigate cold pools - small-scale areas of cold air below raining clouds that often arise during thunderstorms (a sketch of this phenomenon is shown in the figure on the right).



The measurement stations

The measuring stations used were developed and built by at our institute for the special requirements of such a campaign. The stations run autonomously and require neither electricity nor data connection.
As for the main campaign, there are two different types. Which station is used at a location depends on the direct environment and the distribution throughout the city.


Type APOLLO  = Autonomous Cold Pool Logger

  • Measured variables: temperature, air pressure
  • Recording: every second
  • Battery life: 10 to 14 days

Type WXT  = Weather Transmitter Vaisala WXT 536

  • Measured variables: temperature, air humidity, air pressure, wind
  • Recording: every 10 seconds
  • Battery life: infinite (solar powered)

What's new?

A look at the statistics

After a good three weeks of measurements, we are already very satisfied with the incoming files:

  • over 1 GB of data has already been uploaded from 39 different stations (all others are busy collecting and delivering them later)
  • we have the longest continuous series of measurements from an APOLLO station in an allotment garden in Lokstedt (16.5 days, which corresponds to a good 1.4 million individual measurements)
  • the sensitivity of the measuring sensors is obviously high: you can even see small changes in the measuring height of the sensor, such as the drop in air pressure when the mast was erected

drop in air pressure
